INNOSHIELD LITE
INNOSHIELD LITE™ is a economy grade, 10 mil mechanically fastened synthetic roof underlayment engineered to deliver enhanced durability and long-term protection for steep-slope roofing systems.
INNOSHIELD LITE™ is designed for use under asphalt shingles, synthetic shingles, metal in residential applications and primed cedar shakes. INNOSHIELD LITE™ meets all the code requirements including ASTM D226, ASTM 48D69 and AC188 as required by ICC-ES.
Features & Benefits
- Superior traction surface combined with slip resistant bottom coating provides unmatched walkability in dry, wet, or cold conditions.
- All weather performance (-40 °F to 240 °F)
- Eco-Smart Construction: 100% Recyclable Polypropylene Base
- Extended UV Exposure Rating: 180 days
- Limited Lifetime Warranty
- Meets/Exceeds: ASTM D4869: ASTM D226 Type I & II: ASTM D8257: CAN/CSA-A123.3
- Custom Dual Logo Printing Available
-
- Superior traction surface combined with slip resistant bottom coating provides unmatched walkability in dry, wet, or cold conditions.
- All weather performance (-40 °F to 240 °F)
- Eco-Smart Construction: 100% Recyclable Polypropylene Base
- Extended UV Exposure Rating: 180 days
- Limited Lifetime Warranty
- Meets/Exceeds: ASTM D4869: ASTM D226 Type I & II: ASTM D8257: CAN/CSA-A220.1
- Custom Dual Logo Printing Available
| Roll Specifications | Typical Values |
|---|---|
| Roll Width | 48” / 1.22 m |
| Roll Length | 250’ / 76.2 m |
| Roll Weight | 22.5 lb / 10.2 kg |
| Roll Size | 10 sq / 93 m2 |
| Rolls/Pallet/Truck | 64 / 2688 rolls |
| Test / Standard | Typical Values |
|---|---|
| Tensile Strength (ASTM D5034) | MD 96 lb (44 kg) | CD 94 lb (42.7 kg) |
| Tear Strength (ASTM D4533) | MD 18 lbs (8.2 kg) I CD 16 lbs (7.3 kg) |
| UV Exposure (ASTM D8257) | 180 Days |
| Liquid Water Transmission ASTM D4869 | Pass |
| Temperature Range | -40°C to 115°C / -40°F to 240°F |
