STORMFLEX ELITE
STORMFLEX ELITE™ is a premium grade, 20 mil mechanically fastened synthetic roof underlayment engineered to deliver enhanced durability and long-term protection for steep-slope roofing systems.
STORMFLEX ELITE™ is designed for use under asphalt shingles, concrete and clay tiles, all metal panels, synthetic shingles and primed cedar shakes. STORMFLEX ELITE™ meets all the code requirements including ASTM D226, ASTM 48D69 and AC 188 as required by ICC-ES.
Features & Benefits
- Superior traction surface combined with slip resistant bottom coating provides unmatched walkability in dry, wet, or cold conditions.
- All weather performance (-40F to 240F)
- Eco-Smart Construction: 100% Recyclable Polypropylene Base
- Extended UV Exposure Rating: 180 days
- Limited Lifetime Warranty
- Meets/Exceeds: ASTM D4869: ASTM D226 Type I & II: ASTM D8257: CAN/CSA-A220.1
- Custom Dual Logo Printing Available
| Roll Specifications | Typical Values |
|---|---|
| Roll Width | 48” / 1.22 m |
| Roll Length | 250’ / 76.2 m |
| Roll Weight | 35.0 lb / 15.9 kg |
| Roll Size | 10 sq / 93 m2 |
| Rolls/Pallet/Truck | 36 / 1692 rolls |
| Test / Standard | Typical Values |
|---|---|
| Tensile Strength (ASTM D5034) | MD 141 lb (64.0 kg) | CD 127 lb (57.6 kg) |
| Tear Strength (ASTM D4533) | MD 29 lb (13 kg) | CD 24 lb (11 kg) |
| UV Exposure (ASTM D8257) | 180 Days |
| Liquid Water Transmission ASTM D4869 | Pass |
| Temperature Range | -40°C to 115°C / -40°F to 240°F |
